Cablofil
Flexible fire protection for cables penetrating walls — Cablofil’s EZ-Path brochure.

Fire protection

Cablofil has published a 12-page brochure on its EZ-Path fire-protection system for cables passing through walls.

Air-movement web site

Ductwork and air-movement specialist CCL Veloduct has developed a new web site. It has many interactive features and provides a comprehensive guide to the company’s huge range of ductwork, fans and air-movement products.

Lighting

Fagerhult’s Lighting’s latest catalogue brings together the Lyktan range of luminaires and many new Fagerhult products.

Essentials
Well established and basic products that meet or exceed the requirements of Building Regulations are featured in Vent-Axia’s ‘Essentials’ collection.

Vent-Axia’s ‘Essential’ products

Vent-Axia has compiled a special selection of ventilation and heating products for small-commercial and residential applications.

Dalkia
New high-efficiency boiler plant and updated lighting at The Prince Charles Hospital in Wales were funded by a PFI investment.

Refurbish, renew and revitalise

With the need for refurbishment comes the opportunity to improve energy efficiency.

IAN ADAMS explains how the problems of financing such projects can be overcome.

in office
At Mitsubishi Electric in Hatfield, 500 m2 of office on the ground floor are served by a mixed-mode system comprising VRF air conditioning and passive ventilation.

Mixed-mode refurbishment

Delivering comfort conditions using a mix of air conditioning and natural ventilation is much more energy-efficient than air-conditioning alone. A refurbishment project at Mitsubishi Electric shows how.

Office lighting
The latest lighting technology can cut the running cost of fluorescent lighting by 30% compared with installations as little as five years old.

Delivering energy-efficient lighting

HUGH KING discusses the newly emerging sense of commercial reality with energy-efficient lighting.

Belimo
Belimo’s motorised characterised-control valves provided the solution to the energy-efficient refurbishment of controls of the induction air-conditioning system in the ZDF building at Mainz in Germany.

Belimo ball valves key to energy-efficient air-conditioning refurbishment

Both operating and energy-efficiency benefits have been gained using Belimo characterised-control ball valves in the refurbishment of the induction air-conditioning system in the 16-storey building of German broadcasting company ZDF in Mainz, Germany.

Premier Foods
Evaporative cooling using 20 Breezair units provides cooling at Premier Foods with a far smaller energy consumption than conventional air conditioning.

Evaporative systems provide energy-efficient cooling for Premier Foods

Cooling equipment that uses far less energy than conventional air conditioning has been installed at Premier Foods at Bury St Edmunds.

Boosting the energy efficiency of a split air-conditioning system

The development by Airedale of a compact remote electronic-expansion-valve management system (REEV) that can be added to a split air-conditioning system can improve energy efficiency by up to 30% compared with a conventional condensing unit and air-handling unit (AHU).

Stokvis
The energy-efficient replacement of a large, outdated system in Yeatman Hospital which had become unreliable has been achieved using three Stokvis wall-hung condensing boilers.

Stokvis provides cure for hospital boiler problem

Three Stokvis wall-hung condensing boilers have been selected to replace a large, outdated unit in a hospital which had become unreliable.

hospital
The installation of gas turbine CHP and absorption chiller plant at Royal Gwent Hospital are among energy-saving measures funded by a partnership between Honeywell and the Gwent Healthcare NHS Trust.

Partnership approach funds hospital infrastructure work

To provide funding for the replacement of major plant items in two of its hospitals, Gwent Healthcare NHS Trust has entered into a partnership with Honeywell. This approach replaces contract energy management and enables Honeywell to provide a guaranteed level of cost savings for the trust for a 15-year period. The savings amount to about £380 000 a year. The partnership enables Royal Gwent and Neville Hall hospitals to have the most modern equipment that may have been beyond the financial reach of the trust on its own.

ONS
Replacing burners at the Newport site of the Office for National Statistics with three Nu-way XGN burners will improve combustion efficiency and reduce emissions

Nu-way has the right stats for Government office

Combustion efficiency has been increased and emissions reduced following the replacement of dual-fuel (oil/gas) burners at the Newport site of the Office for National Statistics (ONS).

Borstal
Effective heating for this food-preparation in a young-offenders institution is provided by Reznor warm-air heaters.

Original Borstal workshop refurbished with warm-air heating

Warm-air heating that distributes warmth with minimal air movement and no draughts is delivered in a large workshop at HMYOI Rochester by two Reznor V3 gas-fired warm-air heaters. This establishment is the original Borstal of 1902, named after the nearby village.

FA HQ
As part of upgrading work at the FA headquarters in London, An ABB variable-speed drive is providing better control of conditioned air and reducing energy consumption.

ABB scores at Football Association

As part of a wider upgrade of services in the headquarters of the Football Association in London, a 22 kW variable-speed drive from ABB controls the speed of the fan in the air-handling unit to match changing pressure in the air ducts, reducing energy consumption.

Boiler
Ferroli’s Modena 80 boilers are being installed in thousands of council homes across Glasgow to provide efficient heating and hot water.

Glasgow tenants warm to Ferroli

Ferroli combination boilers are providing energy efficient heating and hot water as art of a wide-ranging programme of property improvements by Glasgow Housing Association. Work in thousands of council homes across Glasgow includes new kitchens and bathrooms, rewiring and security upgrades — as well as the installation of Ferroli Modena 80 combi boilers. About 40 new boilers are being installed each week.

WMT
Toshiba air-conditioning systems installed in the refurbishment of this building for WMT near Sheffield qualified for Enhanced Capital Allowances.

Two Toshiba air-conditioning systems share one controller

As part of refurbishment and reorganisation of the headquarters of engineering-parts wholesaler WNT outside Sheffield, Toshiba VRF air-conditioning equipment using R410A dual inverter technology has been installed.

Press-fit
Press-fit fittings and system tube from the XPress Carbon range of Yorkshire Fittings were installed as part of a refurbishment programme at Newcastle Civic Centre.

Modern metallic plumbing systems show their mettle

DAVID HEARNE discusses the benefits of modern metal plumbing systems.

graph
Oversized variable-speed pumps cannot operate to their full potential. The ideal area for operation in the pump-performance curve is A. Pumps operating in area D are oversized. Area B includes pumps that are too large. Pumps in area C of the curve would tend to run at fixed speed.

Enabling variable-speed pumps to deliver performance

With electronic variable-speed pumps being increasingly specified in commercial heating systems, PETER NEARS emphasises that care must be taken to ensure problem-free operation and enable the benefits of energy savings to be achieved.

Doppler device
Fixed clamp-on meters such as this portable Doppler device find application for in-line metering.

Exploiting the benefits of non-invasive liquid measurement

TED FARNON reviews the potential for the non-invasive measurement of liquid flows, levels and energy flow using ultrasonic devices.

boiler cutaway
Scale in this cast-iron boiler section caused a fracture within a year.

The importance of clean systems

If the water and pipework in HVAC systems is contaminated, the consequences can be expensive. GLENN SIMPSON highlights the benefits of clean systems.

pump maintenamce

Faster pump seal changes put to the test

Howard Hall of Andrew Reid & Partners shows how to change a pump seal in just 18 min 45 s. He won a competition at the recent London Hevar exhibition to change the seal on an Armstrong Holden Brook Pullen 4300 pump, earning for himself a DAB digital radio.

Raystede Centre
As part of the upgrade and site rationalisation at The Raystede Centre for Animal Welfare, this new building is equipped throughout with Oventrop valves for heating control.

Oventrop valves contribute to animal welfare

The control of the heating system in a new building at The Raystede Centre for Animal Welfare in Sussex is provided by a wide range of Oventrop valves.

Pump sets
Advancing the art of pressurisation units — the Impress range from Grundfos.

New pressurisation sets designed to Impress

The latest pressurisation sets from Grundfos Pumps are offered as single- and twin-pump versions in two models. They are applicable to sealed heating and chilled-water systems. They detect a reduction in pressure and automatically refill the system, restoring it to its original pressure.

Compupter model
Many Avanti partners are now finding that 3D modelling is a valuable component in true project integration. 3D modelling offers the basis for a single project model to which all partners contribute and extract all design information. (Photo: ZBP)

Enjoying the Avanti effect

TONY MATTHEWS reports on the progress of the Avanti initiative, which is demonstrating the value of information and communication technologies on real construction projects

Cylon
BACnet’s design allows multiple BACnet networks to be connected to create a BACnet internetwork.

How BACnet delivers the right integration at the right level

STEVE KEAR explains why BACnet/IP provides a solution for the complete integration of building systems.

Computer model
Good design and value engineering go hand in hand — and detailed modelling can help identify cost savings. This 3D simulation of a complex secondary school saved £80 000 by checking exactly what specification of glazing would be needed to provide the correct amount of solar shading.

Value engineering meets sustainability

Energy efficiency and sustainability need not be at odds with good, commercial development or be difficult to understand, as multi-disciplinary consultant Gifford is proving.

Preparing for the new Building Regulations

The forthcoming new Building Regulations dealing with the conservation of fuel and power (Part L) and ventilation (Part F) present both challenges and opportunities to the building-services industry. It is a challenge that the Chartered Institution of Building Services Engineering has responded to with the development of much guidance that is widely referred to in the new regulations and in organising a major conference to provide guidance for building designers, constructors, owners and operators.

Andrew Eastwell
A future built on embedded intelligence — BSRIA’s Andrew Eastwell

Chips with everything

A future for the building-services industry of all the components of plant and systems having fully embedded communications capability and intelligence has been suggested by Andrew Eastwell, chief executive of BSRIA. Speaking at the association’s annual briefing in November, he suggested that the ever-falling price of micro-processors is the key to fulfiling what he dubbed the ‘plug-and-play dream’. The event marked 50 years of BSRIA’s role as a leading research organisation in the building-services industry, and Andrew Eastwell was not shy of looking forward.

LG opens UK air-conditioning training academy

LG has invested £500 000 in the development of an air-conditioning training academy that can provide courses for over 240 air-conditioning engineers and contractors each month.

Funding for carbon programme criticised

The announcement by the Government of £30 million of funding for the Low Carbon Building Programme (LCBP) over the next three years has been criticised by the Chartered Institute of Building.

Arsenal

Airedale at Emirates Stadium

Airedale is to supply cooling equipment for critical IT/VT applications at the new Emirates Stadium of Arsenal football club in North London.

Skanska wins PFI hospital scheme in Nottinghamshire

Skanska Innisfree has achieved financial close on a PFI scheme to transform health-care provision for users of three hospitals in central Nottinghamshire.

Government procurement practices found wanting

Procurement practices on Government projects have improved only marginally over the last five years, according to an extensive survey among specialist engineering contractors by the Specialist Engineering Contractors Group. The survey sought feedback on the extent to which best practice on Government projects has permeated along the supply chain and followed a similar survey in 2000.

paint line

Trox enhances its paint lines

A £250 000 investment by Trox in rebuilding and refurbishing its powder-coating plant at Thetford enables one of the two lines to accommodate products up to 5 m long in a huge variety of colours. This line can handle virtually all types of multi-service chilled beam. The other line concentrates on commodity items such as grilles and diffusers.

Apprentice
MP Alun Michael gets a hands-on feel of the new wing of NG Bailey’s training academy in Leeds, which he opened in November. He is pictured with apprentice Ryan Bell.

NG Bailey boosts apprentice training capability

The training academy at NG Bailey in Leeds has been opened by Alun Michael, Minister of State for Industry & the Regions. It boosts Bailey’s training capacity to 400 apprentices.

The Bristolian

SES steams into Swindon

The formal launch of the new office in the south west of SES was celebrated with a soiree at Swindon Steam Museum, with the Lord Mayor of Swindon (left) welcoming this national building-services contractor into the area. Guests included architects, main contractors and clients. Also pictured are managing director Allan McDougall and southern regional director Mark Perkins,

Plant
This packaged ammonia chiller is one of three designed by Star Refrigeration to provide air conditioning for the new Roche headquarters at Welwyn Garden City.

Ammonia and hydrocarbons provide air conditioning and cooling at Roche headquarters

Chillers using ammonia and hydrocarbons have been designed and installed by Star Refrigeration at the new 21 800 m2 headquarters of Roche Products at Shire Park in Welwyn Garden City.

SECC
Severe space restrictions around ductwork for new work associated with the Scottish Exhibition + Conference Centre has been overcome using Koolduct pre-insulated ducting.

Koolduct performs at SECC

The use of Kingspan’s Koolduct pre-insulated ducting at the Scottish Exhibition + Conference Centre in Glasgow has overcome severe space restrictions — especially around the riser ducts.

boiler room
MHS calorifiers and boilers in the Cotman Centre of Norwich & Norfolk University Hospital are achieving high efficiency and low NOx emissions.

MHS provides the remedy for low emissions at hospital

The low energy consumption and emissions of Ultramax boilers and Gemini calorifiers are being exploited in the Cotman Centre of Norwich & Norfolk University Hospital to provide space heating and domestic hot water.

london
Photo-voltaics reaches the City of London — the Bishops Square development in Spitalfields.

Photo-voltaic solar energy enriches City of London

Solarcentury has joined forces with Hammerson UK Properties to install 494 solar panels into the roof of the new Bishops Square development in London’s Spitalfields.

College
Woodland Community College in Harefield, Southampton, is one of three colleges for which Lochinvar has supplied water heaters from its Knight and Charger ranges.

Lochinvar gets top marks at Southampton schools

Extremely fast recovery of hot water for three community schools in Southampton is provided by 14 water heaters from Lochinvar’s Knight and Charger range of gas-fired water heaters.

RIDI
A wide range of luminaires from RIDI Lighting has been installed throughout the London office of Christian Aid.

RIDI aids Christian Aid’s lighting needs

Luminaires from RIDI Lighting have been installed in virtually every area of the 4180 m2 of the London office of Christian Aid. There are six floors, including a basement.

Siemens exercises control for mental-health trust

To support the safe and secure operation of its new personality disorder unit, Newcastle, North Tyneside and Northumberland Mental Health Trust has installed a building-management system based on the Apogee range from Siemens Building Technologies.

fireman
To provide realistic training conditions for firefighters, Nu-way is supplying burners for two facilities in Hereford & Worcester.

Nu-way puts the heat on firefighters

To provide realistic training scenarios for firefighters, Nu-way is providing gas-fired burners at facilities for Hereford & Worcester Fire & Rescue Service and Hereford Fire Station.

office
GIA Lighting Design has applied The Intelligent Solutions lighting-management system to the lighting design strategy for the offices of Gordon Ingram Associates.

Intelligent Solutions provides lighting ambience for office staff

Lighting that mimics the effect of daylight by varying its colour temperature during the day has been devised by GIA Lighting Design for the offices of chartered surveyors Gordon Ingram Associates. The lighting philosophy in the main working space relies on The Intelligent Solutions lighting-management system.

restaurant
Sanyo gas-fired chillers serve the air-conditioning system in the third, and latest, Nobu restaurant in London.

Gas-fired air conditioning serves new London restaurant

Faced with an electricity supply that was inadequate for an electrically powered air-conditioning system, the new Nobu restaurant in the Mayfair area of London has opted for a gas-power solution.

Marigold Court
Well over 3000 m2 of underfloor heating has been installed by Giacomini to provide comfort and safety in this ‘very sheltered housing’ in Gateshead.

Safety and comfort come together with underfloor heating

Underfloor heating in very sheltered housing in Gateshead addresses the issues of providing homes that are inherently safe, economic to run and comfortably designed.

clinic
Fujitsu’s largest VRF air-conditioning system serves this impressive clinic in Ireland.

Fujitsu VRF is just the treatment in Irish clinic

The impressive Galway Clinic in the west of Ireland has become Fujitsu’s largest VRF air-conditioning installation. Fujitsu distributor ICE of Dublin supplied the 36 VRF systems. They serve 183 indoor units in the £100 million clinic, which has a hundred beds and more than doubles the number of private hospital beds available in the area. There are 36 consulting suites used by 97 top medical consultants.

Heat-reflecting membrane boosts performance of Olympic Games building

To reduce heat gain in the shooting range for the Olympic Games in Beijing, a heat-reflecting membrane has been specified for the roof and wall cavities. The contract for Thermo-Foil membrane from Apollo Energy Research in the UK was secured with help from the commercial department of the British Embassy in Beijing.
